WHAT IS TWINLOC

The TwinLoc Suspension System is a proprietary SCOTT Suspension System that allows a rider to control a bikes suspension performance and geometry simultaneously.

With TwinLoc, you can have three bikes in one.

HOW DOES IT WORK?

The system works by connecting the shock, fork, and ultimately the frame via a handlebar remote. With the remote, the user has the ability to choose from three ride modes, Descend, Traction Control and Lockout. Let's explain each of these modes independently.

DESCEND MODE

Our Proprietary FOX Nude shock features two positive air chambers. In Descend mode, both chambers are open, essentially creating one large volume chamber. This gives you the full amount of available rear wheel travel. Both fork and shock are fully optimized for downhill performance with regards to both air spring rate and damping.

TRACTION CONTROL MODE

In Traction Control mode, one chamber is closed off, reducing the shock's air volume. This reduces the effective travel and results in a more progressive air spring curve. This combined with an increase in compression damping leads to a few changes. Primarily, the system changes the bikes geometry when switching from Descend Mode to Traction Control Mode. You sit higher in the shock's travel, ground to pedal clearance is increased, and you effectively move forward into a more efficient position for putting down the power and clearing technical climbs. Additionally, the bike becomes more agile, more nimble and more efficient, all without sacrificing traction or sensitivity. It is perfect for smoother, less technical terrain where you have to pump the bike to gain speed or rough, technical climbs where traction and comfort need to be maximized. Simultaneously, compression damping is increased in the fork in an effort to keep the bike well balanced.

LOCKOUT MODE

The lockout mode is the firmest of all three modes. It is perfect for smooth road or fireroad transitions, or simply riding to the trailhead. The lockout still features a big hit blow off in the event that you hit a rough section, preventing damage to the fork and shock.
